- I have two Nexus devices, last week i upgraded from NXOS 6.03 to 6.1(5a), but when the device had done, i saw the CMP module no response status in on SUP. Here is output in two devices. Everyone have any idea about it.
- Cisco Nexus 7010 Bundle - switch - managed - rack-mountable - with 2 x Cisco Nexus 7000 Series Supervisor 2 Module, 5x Cisco Nexus 7000 Series Fabric-2 Module overview and full product specs on CNET.
BRAND NEW FACTORY SEALED & RETAIL BOXED WITH THE FULL ONE YEAR CISCO WARRANTY!!!
Cisco Nexus 7010 Bundle includes Cisco Nexus 7000 Series Switches, Cisco Nexus 7000 Series Supervisor Module and Cisco Nexus 7000 Fabric Module. The Cisco Nexus 7000 Series Switches combine the highest levels of scalability with operational flexibility. The Cisco Nexus 7000 Series Switches comprise a modular data center-class product line designed for highly scalable 10 Gigabit Ethernet networks with a fabric architecture that scales beyond 15 terabits per second. Designed to meet the requirements of the most mission critical data centers, it delivers continuous system operation and virtualized, pervasive services. The Cisco Nexus 7000 series is based on a proven operating system, with enhanced features to deliver real-time system upgrades with exceptional manageability and serviceability. Its innovative design is purpose built to support end-to-end data center connectivity, consolidating IP, storage, and interprocess communication (IPC) networks onto a single Ethernet fabric. The first in the next generation of switch platforms, the Cisco Nexus 7000 series provides integrated resilience combined with features optimized specifically for the data center for availability, reliability, scalability, and ease of management. The Cisco Nexus 7000 Series Supervisor Module is designed to deliver scalable control plane and management functions for the Cisco Nexus 7000 Series chassis. It is based on a dual core processor that scales the control plane by harnessing the flexibility and power of the dual cores. The supervisors control the Layer 2 and 3 services, redundancy capabilities, configuration management, status monitoring, power and environmental management, and more. It provides centralized arbitration to the system fabric for all line cards. The fully distributed forwarding architecture allows the supervisor to support transparent upgrades to higher forwarding capacity-capable I/O and fabric modules. The supervisor incorporates an innovative dedicated connectivity management processor (CMP) to support remote management and troubleshooting of the complete system. The Cisco Nexus 7000 Fabric Modules for the Cisco Nexus 7000 Series Chassis are separate fabric modules that provide parallel fabric channels to each I/O and supervisor module slot. Up to five simultaneously active fabric modules work together delivering up to 230Gbps per slot. Through the parallel forwarding architecture, a system capacity of more than 8Tbps is achieved with the five fabric modules. The fabric module provides the central switching element for fully distributed forwarding on the I/O modules.
Device Type : Switch - L3 - managed - with 2x Cisco Nexus 7000 Series Supervisor Module, 5x Cisco Nexus 7000 Series Fabric-2 Module
Mar 06, 2018 The Cisco Nexus 7000 10-Slot chassis with up to eight I/O module slots supports up to 384 x 1 and 10 Gigabit Ethernet ports, 48 x 40 Gigabit Ethernet ports, and 16 x 100 Gigabit Ethernet ports, meeting the demands of large data center deployments. It has two dedicated supervisor slots.
Enclosure Type : Rack-mountable - 21U
Subtype : Gigabit Ethernet
Performance : Per slot per fabric : 110 Gbps
Remote Management Protocol : SNMP 1, SNMP 3, SNMP 2c, CLI
Features : Flow control, modular design, layer 3 switching, layer 2 switching, firmware upgradable, Quality of Service (QoS)
Compliant Standards : IEEE 802.1ae
Processor : 2 x Intel Xeon
RAM : 8 GB
Flash Memory : 4 GB
Interfaces : 2 x console - RJ-45 - management 2 x console - RJ-45 2 x USB - Type B 4 x USB - Type A 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 - management
Cisco Nexus 7010 Data Sheet
Expansion Slots : 15 (total) / 8 (free) x expansion slot 4 CompactFlash Card
Installed Modules Qty (Max) : 7 (installed) / 15 (max)
Cisco Part Number : N7K-C7010-BUN2-R, N7K-C7010-BUN-R
UPC : 00882658481772
|PrintRate this content|
Information needed on the Cisco Nexus 7000 line of products including, specifications and and part numbers.
Cisco Nexus 7000 Series Switches combine high levels of scalability with operational flexibility.
Cisco Nexus 7000 Series Switches provide the foundation for Cisco Unified Fabric. They are a modular data center-class product line designed for highly scalable 1/10/40/100 Gigabit Ethernet networks with a fabric architecture that scales beyond 17 terabits per second (Tbps). Designed to meet the requirements of the most mission-critical data centers, the switches deliver continuous system operation and virtualized, pervasive services. The Cisco Nexus 7000 Series is based on the proven Cisco NX-OS Software operating system, with enhanced features to deliver real-time system upgrades with exceptional manageability and serviceability.
The first in the next generation of switch platforms, the Cisco Nexus 7000 Series (Figure 1) provides integrated resilience combined with features optimized specifically for the data center for availability, reliability, scalability, and ease of management.
